General Specs |
| Color | Custom |
| Color-Finish Name | Panel Ready |
| Color/Finish Name | Panel Ready |
| Door Color | Panel Ready |
| Fingerprint Resistant Finish | No |
| Type of Refrigerator | Bottom Freezer Refrigerator |
| Installation Type | Built-In |
| Depth Type | Counter Depth |
| Number of Doors | 2 |
| Total Capacity (cu. ft.) | 20.9 |
| Refrigerator Capacity (cu. ft.) | 15.30 |
| Freezer Capacity (cu. ft.) | 5.56 |
| Freezer Door Type | Pull Out Drawer |
| Door Panel Type | Panel |
| Door Swing Option | Right Hinge |
| Ice Maker Type | Single Ice Maker |
| Ice Maker | Yes |
| Ice/Water Dispenser | No |
| Defrost System | Automatic |
| Refrigeration General Features | Hidden Hinge, Sabbath Mode, Door Alarm |
| Custom Panel Ready | Yes |
| Smart Compatible | No |
| Commercial Use Approved | No |
| Appliance Fit Width (in.) | 36 |
| Width (in.) | 35.75 |
| Depth (in.) | 24 |
| Depth w/Door Open 90 Degrees (in.) | 58.75 |
| Depth Less Door (in.) | 24 |
| Depth Excluding Handles (in.) | 24.75 |
| Depth Including Handles (in.) | 27.38 |
| Height (in.) | 83.13 |
| Height Without Door/Hinge (Case) (in.) | 83.12 |
| Overall Height (in.) | 83.12 |
| Product Weight (lbs.) | 525 |
| Made In The USA | Yes |
| Made In | USA |
| ENERGY STAR Certified | Yes |
| ADA Compliant | No |
| Voltage | 115 |
| Frequency | 60 |
| Amp | 20 |
Additional Dimensions |
| Cabinet Width | 35 in |
| Common Size | 36 in |
| Cutout Depth | 25 in |
| Cutout Width | 36 in |
| Height To Top Of Cabinet | 83.13 in |
| Width Doors Open 90 Degrees | 58.75 |
Exterior Details |
| Base Grille Color | Black |
| Cabinet Finish | Smooth |
| Door Opening Direction | Right |
| Door Style | Flat |
| Reversible Door | No |
Details |
| Design Expression | Panel-Ready |
| Installation Configuration | Built-In |
| Installation Option | Built-In |
| Refrigeration Configuration | Refrigerator |
| Refrigerator Type | Built-In Bottom Mount |
Controls |
| Control Location | Interior Up Front |
| Control Type | Touch Pad |
| Cooling Type | Dual Evaporator |
| LCD Touch Screen | No |
| Max Cool/Fast Cool | Yes |
Certifications |
| ADA Compliant | No |
| CEE Tier Rating | Tier I |
| Prop 65 | Prop 65 warning CALIFORNIA RESIDENTS ONLY - WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov. |
| UL | Yes |
Filter Details |
| Air Filter Indicator/Reset | No |
| Fresh Flow Air Filter Included | Yes |
| Produce Preserver | Yes |
| Water Filter Indicator/Reset | Yes |
| Water Filter Location | Exterior |
| Water Filter Part Number | EDR3RXD1 |
Refrigerator Details |
| Conventional Shelves | 1 Fixed Full-Width Glass, 4 Adjustable Half-Width Glass |
| Humidity-Controlled Crispers | 1 Full-Width, None |
| Liner Finish | Obsidian |
| Non Climate Control Drawers | 1 Full Width, 2 Half Width |
| Refrigerator Door Bins | 1 Adjustable Gallon, 1 Fixed Full-Width Gallon, 2 Dairy, 4 Adjustable Full-Width, 4 Adjustable Half-Width |
| Refrigerator Lighting | Multi-Point Lighting |
| Spill-Proof Glass Shelves | No |
| Temperature-Controlled Drawers | No |
Icemaker Details |
| Icemaker | Factory Installed |
| Icemaker Location | Freezer |
| Types of Ice | No |
Freezer Details |
| Freezer Door Bins | No |
| Freezer Drawer/Basket | 1 Full Width Lower Metal, 1 Full Width Lower Plastic, 1 Full Width Upper Plastic, 2 Half Width Upper Plastic |
| Freezer Number of Shelves | 0 |
| Freezer Shelves | None |
Dispenser Details |
| Dispenser Type | No Dispenser |
Smart Compatibility |
| Connectivity | No |
| Smart Appliance | No |
